B75M DDR3 Motherboard Used

Add to Wishlist
Compare

B75M

  • 100% All Solid Capacitor Design
  • Supports Dual Channel DDR3 1600
  • 1 PCIe 3.0 x16, Supports AMD Quad CrossFireX™ and CrossFireX™
  • PCIE Gigabit LAN
  • Supports Intel® HD Graphics with Built-in Visuals
  • Graphics Output Options : D-Sub, DVI-D, HDMI
  • Combo Cooler Option (C.C.O.)
  • 5.1 CH HD Audio (Realtek ALC662 Audio Codec)
  • Supports ASRock XFast RAM, XFast USB, OMG, Internet Flash, Dehumidifier, UEFI System Browser
  • Supports Intel® Smart Connect, Intel® Rapid Start, Intel® Small Business Advantage

This product is currently out of stock and unavailable.

  • CPU
    – Supports 3rd and 2nd Generation Intel® Core™ i7 / i5 / i3 / Xeon® / Pentium® / Celeron® in LGA1155 Package
    – 3 + 1 Power Phase Design
    – Supports Intel® Turbo Boost 2.0 Technology
    – Supports Hyper-Threading Technology
  • Chipset
    – Intel® B75
    – Supports Intel® Small Business Advantage
    – Supports Intel® Rapid Start Technology and Smart Connect Technology with Intel® Ivy Bridge CPU

    *Intel® Rapid Start Technology and Smart Connect Technology are only supported under Windows® 7 OS or later versions.
  • Memory
    – Dual Channel DDR3 memory technology
    – 2 x DDR3 DIMM slots
    – Supports DDR3 1600/1333/1066 non-ECC, un-buffered memory
    – Max. capacity of system memory: 16GB*
    – Supports Intel® Extreme Memory Profile (XMP) 1.3 / 1.2

    *Due to the operating system limitation, the actual memory size may be less than 4GB for the reservation for system usage under Windows® 32-bit OS. For Windows® 64-bit OS with 64-bit CPU, there is no such limitation.

    **The highest supported DRAM frequency depends on the CPU you’ve installed. For detailed CPU specifications, please refer to Intel® official website.

    ASUS B75M-PLUS Motherboard 1155 M-ATX USB3.0 DDR3 HDMI 4 memory slots – SPCP Computer accessories supplier





SKU: N/A Categories: , , , ,

Based on 0 reviews

0.0 overall
0
0
0
0
0

Be the first to review “B75M DDR3 Motherboard Used”

There are no reviews yet.

Vendor Information

  • Store Name: LK shopper
  • Vendor: LK shopper
  • Address: Samanala Cinema Building, Dambulla Road, Melsiripura
    Kurunegala
    North Western
    60540
  • 4.02 4.02 rating from 54 reviews
